Composers¶

Class¶

class IdentityComposer[source]¶: Copy subsamples to samples verbatim.

class SplatComposer[source]¶

A composer that overwrites current samples with subproblem samples.

class GreedyPathMerge[source]¶

Dialectic-search merge operation [KS]. Generates a path from one input state, representing the thesis, to another input state, representing the antithesis, using a greedy method of single bit flips selected by decreasing energy.

Returns the best sample on the path, which represents the synthesis.

Note: only the lowest-energy sample, is considered from either input state.

See Examples.

References

[KS]	Kadioglu S., Sellmann M. (2009) Dialectic Search. In: Gent I.P. (eds) Principles and Practice of Constraint Programming - CP 2009. CP 2009. Lecture Notes in Computer Science, vol 5732. Springer, Berlin, Heidelberg

Examples¶

SplatComposer¶

This example runs one iteration of a SplatComposer composer, overwriting an initial solution to a 6-variable binary quadratic model of all zeros with a solution to a 3-variable subproblem that was manually set to all ones.

import dimod
from hybrid.composers import SplatComposer
from hybrid.core import State, SampleSet
from hybrid.utils import min_sample

bqm = dimod.BinaryQuadraticModel({t: 0 for t in range(6)},
                                 {(t, (t+1) % 6): 1 for t in range(6)},
                                 0, 'BINARY')

composer = SplatComposer()
state0 = State.from_sample(min_sample(bqm), bqm)
state1 = state0.updated(subsamples=SampleSet.from_samples({3: 1, 4: 1, 5: 1}, 'BINARY', 0.0))

composed_state = composer.run(state1).result()

>>> print(composed_state.samples)
Response(rec.array([([0, 0, 0, 1, 1, 1], 1, 2)],
        dtype=[('sample', 'i1', (6,)), ('num_occurrences', '<i8'), ('energy', '<i8')]), [0, 1, 2, 3, 4, 5], {}, 'BINARY')

GreedyPathMerge¶

This example runs one iteration of a GreedyPathMerge composer on a thesis and antithesis State to find a ground state of a square graph. By inverting the state of variable \(d\) and \(c\) in samples_d and then variable \(a\) of the lowest energy sample of samples_a (second sample), the composer finds a path between these two samples that contains the ground state shown on the right of the top figure.

Square problem with two ground states.

Path from thesis to antithesis.

import dimod
bqm = dimod.BinaryQuadraticModel({}, {'ab': 1.0, 'bc': 1.0, 'cd': 1.0, 'da': 1}, 0, 'SPIN')
samples_d = {'a': 1, 'b': 1, 'c': -1, 'd': -1}
samples_a = [{'a': -1, 'b': -1, 'c': 1, 'd': 1}, {'a': -1, 'b': 1, 'c': 1, 'd': 1}]
states = [hybrid.State.from_samples(samples_d, bqm),
          hybrid.State.from_samples(samples_a, bqm)]
synthesis = GreedyPathMerge().next(states)

>>> print(synthesis.samples)
       a   b   c   d  energy  num_occ.
   0  +1  +1  +1  +1    -4.0         1
   [ 1 rows, 4 variables ]
